Page 15 - CrownB3plus

LI-ION CORDLESS TOOLS

Double speed:
for maximum precision.

Single sleeve keyless chuck
allows an easy one hand Brushless motor for long life,
bit installation/removal. high effi ciency, high endurance,
low noise, low interference.

Built-in Led light allows
work in dark areas
Soft rubber grip:
for longlastig comfort.

Brushless DC electric motors have
permanent magnets which rotate
around a fi xed armature, an electronic
controller replaces the brush/
commutator assembly of the brushed
DC motor.

They offer several advantages: high
torque to weight ratio, more torque per Equipped with 1 hour quick
watt (increased effi ciency), reduced battery charging time.
noise, longer lifetime, and reduced
maintenance operation.

CT21092H-2 BMC CT21091HX-2 BMC CT21090HMX-2 BMC
CT21092H-4 BMC CT21091HX-4 BMC CT21090HMX-4 BMC

NEw NEw NEw

Rated voltage 16 V Max. 20 V Max. 20 V Max.
Battery capacity 2 Ah / 4 Ah 2 Ah / 4 Ah 2 Ah / 4 Ah
Charging time 60 min / 120 min 30 min / 60 min 30 min / 60 min
No-load speed 0-420 / 0-1400 min -1 0-420 / 0-1400 min -1 0-500 / 0-2000 min -1
Torque 21 / 35 Nm 23 / 40 Nm 50 / 80 Nm
Chuck tight. range 0,8-10 mm 2 - 13 mm 1,5 - 13 mm
Drilling output in steel 10 mm 13 mm 13 mm
Drilling output in wood 32 mm 36 mm 40 mm
Max screw diameter M6 M8 M10
Weight 1,06 kg 1,12 kg 1,82 kg

15
